Aluminium kwikstage scaffolding is an easy-to-use, lightweight system that is simple and fast to erect, making it more cost-effective as it saves in labour costs
Main parts of aluminium kwickstage scaffolding
[1] 1.0M Standard [2] 2.0M Standard [3] 3.0M Standard [4] 0.7M Transom/Ledger [5] 1.2M Transom/Ledger [6] 2.5M Ledger [7] 2.5M Ledger w Supp [8] 2.1M Diag End Br (N) [9] 2.4M Diag End Br (W) [10] 3.2M Diag Br 2.5M [11] Screw Jack [12] Deck Hatch 2.5m [13] Deck Plain 1.2m [14] 2.5M Comp T/Board [15] 1.3M Comp T/Board [16] T/Board Bracket [17] 1 Deck Hop Up [18] 275mm Hop Up
The Features of Aluminium Kwikstage Scaffolding Systems
Lightweight components – almost a third of the weight of the steel counterpart. Exceptionally simple to erect certified to 20m. Medium duty with a rating of 450kg per double-width bay. Maximum free-standing height 4m otherwise required to be stabilised with ties to the structure. Steel Kwikstage is a heavier scaffold, suitable for larger projects such as industrial, commercial and mining projects.
Kwikstage Modular Scaffolding
Components are Hot Dipped Galvanised (HDG) which prevents rusting and requires minimal maintenance. Lifetime guarantee on all welds. Highly versatile and simple to erect licensed to 45m. This heavy-duty scaffold is rated at 675kg per bay. Certified to Australian Standards AS/NZ 1576.3 with WorkSafe Design Registration. Trailer Pack available consisting of 15 lineal meters x 4m working platform. Aluminium Stairway eliminates ladders and improves safety and efficiency on site. Tested and approved to Australian Standard AS 1657. Stairway risers in 1.5m segments
